Adjustable Scaffold Floor Wooden Flooring System for Tent Structure

1 / 5

Adjustable Scaffold Floor Wooden Flooring System for Tent Structure

Customization:	Available
Flooring Usage:	It Is Special Designed for The Tents
Main Materials of The Floor:	Plywood with Aluminum Alloy Frame

Send Inquiry

Product Description

Basic Product Information

Model NO.

5m modular

Size

Customized

Color

Brown

Material

Double Brown film faced plywood

Advantages

Anti-Slip, Water-Proof, Heavy Duty

Certification

ISO 9001: 2008

Capacity

100,000sqm/Month

Usage

Modular Tent Structure Flooring

Product Description

The Adjustable Scaffold Wooden Flooring System is a patented product designed specifically for large-scale tent structures. It provides a stable, professional, and high-load-bearing foundation for various outdoor events.

Height from the ground	125mm
Thickness and material	21mm Double Brown film faced plywood (anti-slip, water proof) with hard-pressed aluminum alloy frame
Card board size (L x W x H)	2440x1250x120mm
Weight	70kg/pc
Panel and keel specs	100x50mm with Hot Galvanized Steel Pipe
Main ground beam specs	170x125mm hard-pressed aluminum alloy
Secondary ground beam specs	107x125mm hard-pressed aluminum alloy
Maximum loading	350kg/m2

National Patent Number: ZL201520411043.9

Key Advantages

Custom Design: Specially engineered for professional tent systems.

Durability: Double brown film faced plywood ensures anti-slip and water-proof performance.

High Strength: Hard-pressed aluminum alloy frame is lightweight yet anti-rusty and robust.

Installation Guidance

Step 01: Fix the flooring according to the technical drawing.

Step 02: Install the sub-frame as shown in documentation.

Step 03: For uneven floors, use auxiliary boards first, then install the sub-frame.

Step 04: Securely place the boards on the sub-frame.

Frequently Asked Questions

Q1: Can customized logos be printed on the tent fabric?

Yes. Customized logos can be printed on the tent fabric according to your specific requirements.

Q2: Is the tent structure designed for repeated installation?

Our tents can be assembled and dismantled repeatedly with small transportation size. The aluminum framework has a lifespan of 15-20 years, while PVC fabrics last 5-8 years depending on usage conditions.

Q3: What documents are provided with the product?

We provide a full range of documents including structural drawings, packing lists, installation manuals, and relevant certificates.

Q4: How do I determine the size of the tent needed for an event?

For dining with round tables, allow 10-12 sq. ft per person. For banquet style, allow 8-10 sq. ft per person. For cocktail service, allow 5-6 sq. ft per person.

Q5: Is the tent stable enough for high winds?

Yes. The main frameworks are manufactured with high-impact extruded anodized aluminum (6061/T6), allowing the structure to resist wind speeds up to 100 km/hr.

Q6: What is the warranty period for the products?

We provide a one-year guarantee. During this period, we will repair or replace any parts damaged due to quality issues.
